High-Speed Roll-Up Doors
Perfect for high-traffic areas, high-speed roll-up doors feature responsive lifting and lowering as well as breakaway design that can reduce damage and the cost of repairs in case of an accident. Our high-speed industrial roll-up doors offer safety and protection, low maintenance and a variety of colors that allow you to customize your product. Moving at speeds of up to 100 inches per second, our high-speed roll-up doors can handle the most challenging of high traffic areas, keeping workers and inventory safe and protected. Enjoy the benefits of advanced performance that maximizes safety and minimizes safety. Find each model in a range of standard colors, including blue, orange, yellow, red and gray.
MODEL 880 ADV-XTREME
Flexible Bottom Interior High Speed Fabric Door
Designed for high traffic areas where safety is a priority, Wayne Dalton’s Model 880 ADV-Xtreme interior high speed fabric door features a flexible bottom with a detachable bottom seal that diminishes the potential for injury. This door is perfect for manufacturing, healthcare and warehouse facilities.
Model 880 ADV-Xtreme is made with two layers of PVC-coated polyester and 1 layer of polyester weave and its strutless design lowers the operational noise of the door for quiet and smooth operation. This door is capable of withstanding pressure of up to +3.0/-3.0 psf.
- Max Width: 12’
- Max Height: 12’
- Interior applications
- Material: 2 layers of PVC-coated polyester with 1 layer of polyester weave
- Wind load*: up to +3.0/-3.0 psf
- Opening speed: up to 70” per second
- Closing speed: up to 40” per second
- Breakaway self-reset
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
Design Features
High Performance, Low Maintenance Design
- Strutless design lowers the operational noise of the door for quiet and smooth operation
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
Safety Focused
- Flexible bottom diminishes the potential for injury
- Wireless monitored reversing edge immediately stops and reverses the door when an obstacle is detected
- Two sets of safety obstruction sensors
Field Repairable
- Patent-pending breakaway system design with impact detection and push button self-repair
- Patent-pending curtain lock makes this door easy to repair in the field
- Detachable bottom seal in safety yellow for easy replacement and troubleshooting
Applications
- Manufacturing / Heavy Manufacturing
- Warehouse / Distribution
- Pharmaceutical
- Food and Beverage
*Wind load is the ultimate pressure tested at a door width of 12′.
MODEL 881 ADV-XTREME
Interior High Speed Fabric Doors
Wayne Dalton’s Model 881 ADV-Xtreme interior high speed fabric door is designed to be used indoors in high traffic and environmentally controlled areas. It is ideal for distribution and manufacturing facilities that require controlled environments or where there’s high traffic from forklift operation.
Model 881 ADV-Xtreme’s airtight design prevents airborne contaminants from entering the controlled and non-controlled environments and reduces air exchange to no higher than .236 cfm/sf (ASTM E-283). The door’s strutless design lowers the operational noise of the door for quiet and smooth operation. Model 881 is capable of withstanding pressure of up to +7.5/-7.5 psf, making it an excellent option to separate high and low pressure rooms in large facilities.
- Max Width: 14’
- Max Height: 14’
- Interior applications
- Material: 2 layers of PVC-coated polyester with 1 layer of polyester weave
- Wind load*: up to +7.5/-7.5 psf
- Opening speed: up to 70” per second
- Closing speed: up to 40” per second
- Breakaway self-reset
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
Design Features
High Performance Design
- Strutless design lowers the operational noise of the door for quiet and smooth operation
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
Independently-Tested Airtight Design
- Prevents airborne contaminants from entering a controlled environment
- Reduces air exchange to no higher than .236 cfm/sf (ASTM E-283)
Field Repairable
- Patent-pending breakaway system design with impact detection and push button self-repair
- Patent-pending curtain lock makes door easy to repair in the field
Applications
- Manufacturing / Heavy Manufacturing
- Warehouse / Distribution
- Pharmaceutical
- Cold Storage
- Food and Beverage
*Wind load is the ultimate pressure tested at a door width of 10′.
MODEL 882 ADV-XTREME
Strutted Interior & Exterior High Speed Fabric Doors
Our Model 882 ADV-Xtreme strutted interior high speed fabric door is a lightweight and durable door that’s ideal for manufacturing, warehouse and distribution facilities. This high speed door is built to last.
Model 882 ADV-Xtreme’s strutted design allows for quick section replacement, while reducing curtain deflection under pressure. This door is capable of withstanding pressure of up to +4/-4 psf. It is designed to be low maintenance and includes such features as breakaway impact detection and push button self-repair, along with plug and play wiring.
- Max Width: 16’
- Max Height: 15’
- Interior & Exterior applications
- Material: 2 layers of PVC-coated polyester with 1 layer of polyester weave (for interior applications)
- Material: 3-Layer PVC, 2-layer polyester weave (for exterior applications)
- Wind load*: up to +4.0/-4.0 psf
- Opening speed: up to 65” per second
- Closing speed: up to 40” per second
- Breakaway self-reset
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
Design Features
High Performance, Low Maintenance Design
- Strutted design allows for quick section replacement while reducing curtain deflection under pressure
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
- Patent-pending breakaway system design with impact detection and push button self-repair
Applications
- Manufacturing / Heavy Manufacturing
- Warehouse / Distribution
- Food and Beverage
- Cold Storage
*Wind load is the ultimate pressure tested at a door width of 16′.
MODEL 883 ADV-XTREME
Strutted Interior & Exterior High Speed Fabric Doors
Made of a rugged fabric material, Wayne Dalton’s Model 883 ADV-Xtreme strutted high speed fabric door is designed for applications where a fast-acting exterior door is needed.
Model 883 ADV-Xtreme’s strutted design allows for quick section replacement, while reducing curtain deflection under pressure. This door is capable of withstanding pressure of up to +19.5/-19.5 psf. Model 883 ADV-Xtreme is designed to be low maintenance and includes such features as breakaway impact detection and push button self-repair, along with plug and play wiring.
- Max Width: 20’
- Max Height: 20’
- Exterior applications
- Material: 3 layers of PVC-coated polyester with 2 layers of polyester weave
- Wind load*: up to +19.5/-19.5 psf
- Opening speed: up to 65” per second
- Closing speed: up to 40” per second
- Breakaway self-reset
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
- Strutted design with roller system
Design Features
High Performance, Low Maintenance Design
- Strutted design allows for quick section replacement while reducing curtain deflection under pressure
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
- Patent-pending breakaway system design with impact detection and push button self-repair
Rugged Fabric Material Construction
- Ideal for exterior door applications
- Rough environment interior applications
Applications
- Manufacturing / Heavy Manufacturing
- Warehouse / Distribution
- Parking Garages
- Auto / Transit
- Food and Beverage
*Wind load is the ultimate pressure tested at a door width of 16′.
MODEL 884 ADV-XTREME
Fabric Strutted Exterior Doors Heaviest Fabric Door
The heaviest fabric door in the ADV-Xtreme series, Model 884 ADV-Xtreme is designed for exterior applications where weather elements may be extreme. The patent-pending articulating roller wind strut reduces noise and allows the door to operate under wind load.
This door’s strutted design allows for quick section replacement, while reducing curtain deflection under pressure. This door is capable of withstanding pressure of up to +22.0/-22.0 psf. Model 884 ADV-Xtreme is also designed to be low maintenance and includes such features as breakaway impact detection and push button self-repair, along with plug and play wiring.
- Max Width: 24’
- Max Height: 18’ at 24′ wide / 20′ at 23′ wide
- Exterior applications
- Material: 3 layers of PVC-coated polyester with 2 layers of polyester weave
- Wind load*: up to +22.0/-22.0 psf
- Opening speed: up to 55” per second
- Closing speed: up to 40” per second
- Breakaway self-reset
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
Design Features
High Performance, Low Maintenance Design
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
- Patent-pending breakaway system design with impact detection and push button self-repair
Performance Under Pressure
- Patent-pending articulating roller wind strut reduces noise and allows for quick panel replacement while reducing curtain deflection under pressure and also allows door to operate under wind load
- Strutted design allows for quick panel replacement while reducing curtain deflection under pressure
- Heavy-duty .188″ high strength steel guides are ideal for high pressure areas.
Bottom Windlock
- A button windlock provides additional static pressure resistance.
Rugged Fabric Construction
- Ideal for exterior applications
- Rough environment interior applications
Applications
- Manufacturing / Heavy Manufacturing
- Warehouse / Distribution
- Large Opening
- Mining
- Parking Garages
- Auto / Transit
*Wind load is the ultimate pressure tested at a door width of 20′
MODEL 885 ADV-XTREME
Exterior High Speed Rubber Doors
The heaviest fabric door in the ADV-Xtreme series, Model 884 ADV-Xtreme is designed for exterior applications where weather elements may be extreme. The patent-pending articulating roller wind strut reduces noise and allows the door to operate under wind load.
This door’s strutted design allows for quick section replacement, while reducing curtain deflection under pressure. This door is capable of withstanding pressure of up to +22.0/-22.0 psf. Model 884 ADV-Xtreme is also designed to be low maintenance and includes such features as breakaway impact detection and push button self-repair, along with plug and play wiring.
- Max Width: 30’
- Max Height: 30’
- Exterior applications
- Material: 5 layers of NBR rubber with 4 layers of polyester weave
- Wind load*: up to +27.0/-27.0 psf
- Opening speed: up to 50” per second
- Closing speed: up to 40” per second
- Breakaway self-reset
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
Design Features
Rugged Construction
- Multi-layered, reinforced rubber provides added strength without the weight
- Ideal for harsh exterior conditions with a wind load of up to 27.0 psf
- Nitrile butadiene rubber (NBR) provides resistance to petrochemicals for easy cleaning
High Cycle, Low Maintenance Design
- Springless design requires minimal interruption for maintenance and push
- Patent-pending breakaway system design with impact detection and push button self-repair
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
Applications
- Manufacturing / Heavy Manufacturing
- Warehouse / Distribution
- Mining
- Auto and Transit
- Parking Garages
- Large Openings
*Wind load is the ultimate pressure tested at a door width of 19′
MODEL 887 ADV-XTREME
Insulated High Speed Doors Interior Freezer & Cooler Doors
Designed for thermal control and ideal for cold and food and beverage storage, Model 887 ADV-Xtreme features an insulated curtain with actively heated guides that ensures a uniform temperature and smooth door movement.
The innovative springless design requires minimal interruption for maintenance and the curtain comes pre-wrapped, ready for installation. Pre-wired motor, guide heater and air curtain connection and plug and play accessories help reduce the need for a licensed electrician.
- Max Width: 12’
- Max Height: 18’
- Interior applications
- Material: PVC-coated polyester plus radiant insulation
- Wind load*: up to +2/-2 psf
- Opening speed: up to 80” per second
- Closing speed: up to 40” per second
- Operation: direct-drive motor and gearbox system
- Control: variable frequency drive
- Wireless reversing edge
- Plug and play wiring
*Wind load is the ultimate pressure tested at a door width of 10′.
Design Features
Thermal Performance
- Insulated curtain provides a barrier to prevent heat loss and condensation
- Actively heated guides ensure the entire guide has a uniform temperature for smooth operation
- Quad-sealed, insulated guides prevent guide condensation and conditioned air loss around the curtain
High Performance Design
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
- Breakaway bottom bar is easily reset from either side of the opening in case of accidental forklift contact
- Pre-wired motor, guide heater and air curtain connection, and plug and play accessories reduce the need for a licensed electrician
Safety Focused
- Two sets of safety photo eye sensors
- Monitored wireless reversing edge
Applications
- Cold Storage
- Food and Beverage
- Warehouse / Distribution
MODEL 888 ADV-XTREME
High Speed Metal Doors
Built tough with power, security and durability in mind, Model 888 ADV-Xtreme is ideal for applications where security and performance are a priority. Constructed with dual-walled aluminum, this door can withstand pressure up to +100/-100 psf.
Model 888 ADV-Xtreme also features a patent-pending helical-designed steel headplate that helps prevent metal curtain contact and provides smooth operation. A patent-pending curtain monitoring device ensures the door has a redundant system to monitor the position of the door.
- Max Width: 26’
- Max Height: 21’
- Exterior applications
- Material: Dual-walled aluminum
- Wind load*: up to +100/-100** psf
- Opening speed: up to 80” per second
- Closing speed: up to 20” per second
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Plug and play wiring
Design Features
High Performance Design
- Springless design for over 1 million cycles and requires minimal interruption for maintenance
- Gravity drive system coupled with variable frequency drive eliminates sudden jolts from door start/stop
- Direct-mounted gear drive minimizes wear and tear
Durable Construction
- Dual-walled, solid aluminum curtain for security and privacy
- Steel headplate utilizes high strength, durable rollers to prevent metal curtain contact and provides smooth operation
Safety Focused
- Patent-pending integrated curtain monitoring device ensures the door has a redundant system to monitor the position of the door
- Safety light curtain minimizes contact with objects in the doorway
- Monitored wireless reversing edge
Applications
- Parking Garages
- Manufacturing
- Auto Dealerships
*Wind load is the ultimate pressure tested at a door width of 15′
**Up to +50/-50 psf with optional vision panels
MODEL 889 ADV-XTREME
Exterior Full-View High Speed Metal Doors
A high speed door with visibility and durability, Model 889 ADV-Xtreme is ideal for applications where aesthetics and visibility are a priority. Constructed with a fully assembled curtain, this door is easy to install and maintain.
Model 889 ADV-Xtreme also features a patent-pending helical-designed steel headplate that helps prevent metal curtain contact and provides smooth operation. A patent-pending curtain monitoring device ensures the door has a redundant system to monitor the position of the door.
- Max Width: 20’
- Max Height: 21’
- Exterior applications
- Material: aluminum and scratch-resistant polycarbonate
- Wind load* up to +50/-50 psf
- Opening speed: up to 80” per second
- Closing speed: up to 20” per second
- Operator: direct-drive motor and gearbox system
- Control: variable frequency drive
- Plug and play wiring
Design Features
High Performance Design
- Springless design for over 1 million cycles and requires minimal interruption for maintenance
- Gravity drive system coupled with variable frequency drive eliminates sudden jolts from door start/stop
- Direct-mounted gear drive minimizes wear and tear
Durable Construction
- Full-view door with corrosion-resistant aluminum and clear vision, impact-resistant polycarbonate panels
- Steel headplate utilizes high strength, durable rollers to prevent metal curtain contact and provides smooth operation
- Independently-tested and capable of withstanding pressure of up to +50/-50 psf
Safety Focused
- Patent-pending integrated curtain monitoring device ensures the door has a redundant system to monitor the position of the door
- Safety light curtain minimizes contact with objects in the doorway
- Monitored wireless reversing edge
Applications
- Auto Dealerships
- Retail
- Manufacturing
*Wind load is the ultimate pressure tested at a door width of 15′
